Operators

Operators can be broken down into 5 distinct types:

1. Arithmetic (Add, Subtract, Multiply, Divide, Modulo etc)
2. Assignment (Assign, Subtract Equals, Add Equals, Multiply Equals etc)
3. Bitwise - (AND, OR, XOR, NOT, Left Shift, Right Shift)
4. Comparison - (Greater Than, Less Than, Equal, Not Equal etc)
5. Logical - (And, Or)

To add these to your language there is an equivalent template class for each type defined within LARF. Using Arithmetic operators as an example, if we wanted to define our operator set we would create a new class e.g. MyArithmeticOperators and extend that class by ArithmeticOperator. This would require us to define several methods:

public class SLOPArithmeticOperator extends ArithmeticOperator {

    public SLOPArithmeticOperator(String value) {
        super(value);
    }

    @Override
    public Token<String> createToken(String value) {
        return new SLOPArithmeticOperator(value);
    }

    @Override
    public String getPattern() {
        return "^(\\+\\+|--|\\+|-|\\*|\\/|%)";
    }

    @Override
    protected void initOperators() {
        addOperator("+", ArithmeticOperatorType.ADD);
        addOperator("-", ArithmeticOperatorType.SUBTRACT);
        addOperator("*", ArithmeticOperatorType.MULTIPLY);
        addOperator("/", ArithmeticOperatorType.DIVIDE);
        addOperator("%", ArithmeticOperatorType.MODULO);
        addOperator("++", ArithmeticOperatorType.INCREMENT);
        addOperator("--", ArithmeticOperatorType.INCREMENT);
    }

    @Override
    public String[][] getOperatorOrder() {
        return new String[][] {
                {"++", "--"},
                {"*", "/", "%"},
                {"+", "-"}
        };
    }
}

This class is used to match and store each operator as it is found in code. The pattern is a regular expression used to make the initial match and is then stored as a value via the createToken method / constructor. This class also defines the supported operator types as well as what their String equivalent should be. These are defined in the initOperators method using the addOperator(..) method. For an arithmetic operator, we define each type by using the ArithmeticOperatorType enum.

Ensure correct regex order

Please ensure that you've declared your regular expression pattern correctly. Otherwise this could lead to an operator never being matched if another one matches less characters that precedes it. For example, placing + before ++ would cause this scenario. This is because an increment would be matched as two add operators. As such, when defining your pattern, ensure you place the longer match before the shorter one e.g. ^(\\+\\+|\\+)

Operator classes for the most part use a similar naming style, but for completeness please the full table is below:

Operator Type	Template Class	Type Enum
Arithmetic	ArithmeticOperator	ArithmeticOperatorType
Assignment	AssignmentOperator	AssignmentOperatorType
Bitwise	BitwiseOperator	BitwiseOperatorType
Comparison	ComparisonOperator	ComparisonOperatorType
Logical	LogicOperator	LogicalOperatorType

Custom Operators

You are not restricted to using those common operators. If you'd like to define them all yourself or just a single set, you can follow the following steps:

1. Create a new enum class that represents your custom operators

   public enum MyCustomOperators {
       SQUARE,
       SQUARE_ROOT
   }

2. Define a concrete class for your Operators e.g. CustomOperators and extend the OperatorHandler class while passing in your enum as a generic type.

   Ensure correct regex order

   You'll also need to pass the class of your operator enum type in the constructor for these custom operator classes. This is not necessary when using the standard operator templates.

   public class CustomOperators extends OperatorHandler<MyCustomOperators> {

       protected CustomOperators(String value) {
           super(MyCustomOperators.class, "Custom Operator", value);
       }

       @Override
       public PatternType getPatternType() {
           return PatternType.REGEX;
       }

       @Override
       public Optional<String> getGuidance(String token, List<Integer> groupsCount) {
           return Optional.empty();
       }

       @Override
       public List<Token<?>> process(LARFParser parser, LARFContext context, LARFConfig config) {
           return Collections.singletonList(this);
       }

       @Override
       public String getPattern() {
           return "^(\\^|_/)";
       }

       @Override
       protected void initOperators() {
           // 4 ^ 2 = 16
           addOperator("^", MyCustomOperators.SQUARE);
           // _/16 = 4
           addOperator("_/", MyCustomOperators.SQUARE_ROOT,
                 Collections.singletonList(Operands.RIGHT_HAND_SIDE));
       }

       @Override
       public String[][] getOperatorOrder() {
           return new String[][] {
                {"^", "_/"}
           };
       };

       @Override
       public int getHandlerOrder() {
           return 1;
       }
   }

   You'll notice that on the square root operator above, we're passing in another parameter. This is a list of applicable operands that can be used with the operator. The default is Operands.BOTH where the operator takes both a left and right side. In this case though the square root only take a right-side operand and cannot be used in any other situation.

3. Modify your operation class and handle both operator types within the process method:

   @Override
   public Token<?> process(LARFConfig config, LARFContext context, Token<?> firstToken, OperatorHandler<?> operator,
                           Token<?> secondToken, UnhandledEvent unhandledEvent) {
       BigDecimal first = Objects.isNull(firstToken.getValue()) ?
               BigDecimal.ZERO : new BigDecimal(firstToken.getValue().toString());
       BigDecimal second = Objects.isNull(secondToken.getValue()) ?
               BigDecimal.ZERO : new BigDecimal(secondToken.getValue().toString());
       if (operator instanceof ArithmeticOperator) {
           //...
       } else if (operator instanceof IndentCustomOperator) {
           switch (((IndentCustomOperator)operator).getOpType()) {
              case SQUARE: return convert(first.pow(second.abs().intValue()));
              case SQUARE_ROOT: return convert(BigDecimal.valueOf(Math.sqrt(second.doubleValue())));
           }
       }
       return unhandledEvent.trigger();
   }

4. Add your custom operator class to the configuration file:

   @Override
   protected void initOperators() {
       //...
       addOperatorHandler(new IndentCustomOperator(null));
   }

5. Give it a try:

   Indent Language Test Utility
   ============================
   4 ^ 2
   Result: 16 (Type: Integer, Time taken: 26ms)
   _/16
   Result: 4 (Type: Integer, Time taken: 3ms)
